Aluminum Plate

2A12 aluminium sheet

2A12 aluminium sheet is a kind of high strength hard aluminium, which can be strengthened by heat treatment. It has moderate plasticity in annealing, hardening and hot state, good spot welding performance, and the tendency to form intergranular cracks in gas welding and argon arc welding. The alloy has good machinability after quenching and cold work hardening, and poor annealing performance. The corrosion resistance is not high. Anodic oxidation treatment and painting method or aluminium coating on the surface are often used to improve the corrosion resistance.

1) Chemical constituents:

Mg：1.2～1.8

Zn：≤0.30

Mn：0.30～0.9

Ti ：≤0.15

Ni：≤0.10

Fe： 0.000～ 0.500

Fe+Ni： 0.000～ 0.50

2) Application:

Aircraft structure (skin, skeleton, rib beam, partition frame, etc.), rivets, missile components, truck hub, propeller components and other structural components.

3) Heat treatment status:

4) Domestic Spot Specification, Calculating Formula:

Aluminum sheet. It is customary in the world to call aluminium sheet or aluminium sheet with thickness over 0.2 mm, width below 500 mm, width above 200 mm and length less than 16 m, foil below 0.2 mm and layout or strip within 200 mm width (of course, with the progress of large equipment, the width of Xindatong now can reach 600 mm is more). Aluminum rod, diameter: 3-500 mm aluminium tube, thickness: 2-500 mm

The following are the theoretical formulas for calculating aluminium tube, aluminium plate and aluminium rod.

Aluminum sheet weight (kg) = 0.00271 x thickness x width x Length

Aluminum tube weight (kg) = 0.00879 x wall thickness x (outer diameter - wall thickness) x length

Aluminium bar (kg) = 0.0022 x diameter x diameter x Length
